Location
- Search by name, click on the map or enter coordinates
- NASA POWER, Global Solar Atlas and regional hourly sources
- Or enter your own measured data
- Annual GHI
- 1,798.7kWh/m²
PVQuick PV Design Software · Professional · Quick · Easy to use
PV design, from site
to feasibility report
Five steps take you from choosing the site to a preliminary design and feasibility report.
First-year energy
2,325.9MWh
P50 · P90
2,325.9·2,172.6MWh
P90 is the 10-year average
Project IRR (after tax)
11.97%
Payback 7.51 years (after tax)
Calculated by the software for an example project: 1 MW 2-axis tracking plant at Golmud, China, default assumptions
PVQuick XiaofuPilot
The AI agent in the software and the AI Hub. Drag it to turn it.
Solar time11:00trackers follow the sun
- 10mounting types
- 1,290optimized inverter units
- 8760hours, calculated hourly
- 5steps to a report
WCPEC-9
Meet us at WCPEC-9,
booth W-26
PVQuick is exhibiting at WCPEC-9. Come by the booth to see the software and talk about your project.
- Booth
- W-26
- Venue
- DCC, Daejeon, Korea
- Industry Forum talk
- Nov 18, 15:10
Features
Everything a PV project needs, from the site to the feasibility report.
Site, equipment, energy, investment and report run on one calculation chain, with no data to carry between tools.
Equipment & Land Use
- 3 categories, 10 operating modes
- 1,290 pre-optimized inverter units
- Row spacing and land use calculated, with a 3D view
- PV capacity
- 1,094.4kWp
- Inverter units
- 20
Irradiation & Yield
- Non-isotropic irradiation model in 20-minute steps
- Inter-row shading computed geometrically at every step
- Performance ratio from 15 editable efficiency items
- First-year energy
- 2,325.9MWh
- Performance ratio
- 84.26%
Economics & GHG
- Capital cost, O&M and LCOE
- IRR, NPV and payback, or the tariff for a target IRR
- CO₂, SO₂, NOₓ and standard coal saved
- Project IRR (after tax)
- 11.97%
- CO₂ avoided over 25 years
- 29,417t
Report
- A complete preliminary design and feasibility report
- In English or Chinese, ready to print or save as PDF
- Layouts export to PDF, DXF and KML
- Export
- PDFDXFKML
3 Categories, 10 Operating Modes
Fixed, manual adjustment and eight tracking modes, for distributed PV on roofs and elevated structures and for ground-mounted plants on flat or sloped land.
1,290
optimized inverter units
Choose the inverter power and PVQuick takes the matching unit: modules per string, strings per inverter and the DC/AC ratio.
3P50kW-(570W×12)×8/1.09The inverter unit taken for the example project
PV + Storage and Street Lights
Beyond grid-tied PV: household and commercial PV + battery storage sized from the load, and off-grid solar street lights checked night by night against years of NASA daily weather data.
A complete feasibility report
Preliminary design and feasibility report, ready to print or save as PDF.
Figures and images are the software’s results for an example project: a 1 MW 2-axis tracking plant at Golmud, China, default assumptions.
Capabilities
Key Capabilities
8,760-hour calculation
hourly weather and hourly energy output for the whole year, ready to download.
P50/P90 energy yield
a reference for investment decisions, included in the report.
Hourly load profiles
upload a full-year profile to see self-consumption and battery cycling at a glance.
Layout on the map (pilot)
import the site boundary, avoid water, steep slopes and keep-out areas, lay out automatically and export DXF or KML.
Quick design
enter a few inputs for a first design, then turn it into a full project.
AI agent
built into the software, on duty 24 hours a day to answer your professional questions.
Accuracy
Comparison with public measured data
Annual error against published measurements (mean absolute), using on-site measured weather.
0.3%
Front-side POA irradiation
PVPMC 2021 public data, 6 scenarios
0.9%
DC energy
DTU (Denmark), 4 research arrays, site-measured losses
2.1%
AC energy
Golden campus (NREL lab), 5 systems; inverters as installed, other losses at defaults
| Public data set | Quantity | Inputs | Annual error of each system (%) | Mean abs. error |
|---|---|---|---|---|
| Golden campus (NREL lab), 5 systems, 2011–2012 | AC energy | Measured weather; inverters as installed, other losses at defaults | +0.8 +1.5 −1.6 +0.6 +6.2 | 2.1% |
| PVPMC 2021 comparison, 6 scenarios | Front-side POA irradiation | Inputs given to the participants | −0.4 −0.4 +0.2 −0.1 −0.4 −0.5 | 0.3% |
| DTU Roskilde, 4 arrays, 2019–2020 | DC energy | Measured weather; site-measured losses (about 2.3%) | +1.5 −0.5 −0.3 −1.2 | 0.9% |
PVQuick November 2026 version. Row 1: we ran PVQuick on five photovoltaic systems at NREL’s Golden, Colorado campus, using the publicly available 2011–2012 on-site measured weather data. The same data set was used in NREL’s 2014 software validation study (Freeman et al., NREL/TP-6A20-61497). Row 2: PVQuick did not take part in the 2021 PVPMC blind modeling comparison; we ran it after the measured data were published (Theristis et al. 2023, doi:10.1002/pip.3729; data: Theristis & Stein 2023, doi:10.21948/1970772). Row 3: Technical University of Denmark (Riedel-Lyngskær et al. 2020, doi:10.3390/app10238487; data under CC BY 4.0, doi:10.11583/DTU.13580759). Results with default loss factors on request: support@pvquick.com. The PVQuick team carried out these calculations. They do not represent validation or endorsement by NLR, NREL, the Alliance, the U.S. Department of Energy, Sandia, DuraMat, PVPMC or DTU.
Scope
What it covers
Solar resource data cover any site globally; equipment and cost data cover China, the USA and Europe; project sizes range from a few kW to 300 MW.
Ground-mounted PV plants
Flat terrain with ten mounting types (by latitude), or sloped land following the slope or terraced.
Array-installed distributed PV
Tilted arrays with calculated row spacing: flat roofs, water-surface PV, elevated structures.
Flat-laid distributed PV
Modules flat on the roof plane: pitched roofs, greenhouses, façades, carports, PV balconies.
Worldwide Solar Resource QueriesSolar resource and hourly weather queries by name, map or coordinates worldwide, subject to data coverage. Quick design, equipment defaults and full financial analysis currently cover China, the USA and Europe.
Show Xiaofu
Drag to turn it
PVQuick XiaofuPilot
PVQuick Xiaofu is the AI agent we have built into the PVQuick software and the AI Hub.
Answers questions in the software
It sees your project and the page you are on, explains the inputs and results, and tells you what to fill in next.
Fills in for you
It can change project inputs, start a new project or open a step. It shows a confirmation card first and acts only after you confirm.
Replies first and collects feedback on AI Hub
Xiaofu replies to new posts first and collects users' questions and suggestions; PV experts and the team follow up.
Pilot. AI answers are for reference.
pvquick.net
PVQuick AI Hub
Report problems, suggest features, ask questions and talk solar PV with other professionals at pvquick.net, with AI keeping it organized.
Building an AI-powered hub for solar PV
Every user is both a participant and a beneficiary.
- 1
Sign up
One PVQuick account; 25 welcome points on sign-up
- 2
Ask, report, suggest
Use Feedback in the app, or post on AI Hub
- 3
AI and experts answer
Xiaofu, the PVQuick AI Agent, answers first; PV experts and the team follow up
- 4
Better releases
Accepted reports and ideas go into the next release
- 5
Earn points
+5 when accepted, +5 for a confirmed solution, +1 for a post the AI finds useful (up to 3 a week)
- 6
Unlock features, earn Pro
Points unlock full reports and more projects; 15, 40 and 100 contribution bring 1, 2 and 3 months of Pro at the full release
After each release, back to step 2: keep using it, keep reporting
We have built PVQuick into Xiaofu, the PVQuick AI Agent, now in trial. On AI Hub, Xiaofu offers suggestions and explanations on questions about PVQuick, in many conversations at once, and keeps evolving.
- General PV discussion: design, equipment, O&M, policy… questions get AI and expert replies too
